2Gb: x16, x32 Mobile LPDDR2 SDRAM S4
Clock Specification
Clock Specification
The specified clock jitter is a random jitter with Gaussian distribution. Input clocks vio-
lating minimum or maximum values may result in device malfunction.
Table 83: Definitions and Calculations
Symbol
Description
Calculation
Notes
t CK(avg)
n CK
and
The average clock period across any consecutive
200-cycle window. Each clock period is calculated tCK(avg) =
N
tCK j /N
from rising clock edge to rising clock edge.
Unit t CK(avg) represents the actual clock average
t CK(avg)of the input clock under operation. Unit
n CK represents one clock cycle of the input clock,
counting from actual clock edge to actual clock
edge.
t CK(avg)can change no more than ±1% within a
100-clock-cycle window, provided that all jitter
and timing specifications are met.
j=1
Where N = 200
t CK(abs)
t CH(avg)
The absolute clock period, as measured from one
rising clock edge to the next consecutive rising
clock edge.
The average HIGH pulse width, as calculated
N
1
across any 200 consecutive HIGH pulses.
tCH(avg) =
tCH j
/ ( N × tCK(avg))
j=1
Where N = 200
t CL(avg)
The average LOW pulse width, as calculated
N
across any 200 consecutive LOW pulses.
tCL(avg) =
tCL
j
/( N × tCK(avg))
j=1
Where N = 200
t JIT(per)
t JIT(per),act
t JIT(per),
The single-period jitter defined as the largest de-
viation of any signal t CK from t CK(avg).
The actual clock jitter for a given system.
The specified clock period jitter allowance.
tJIT(per) = min/max of tCK i – tCK(avg)
Where i = 1 to 200
1
allowed
tJIT(cc) = max of tCK
i + 1 – CK i
t JIT(cc)
The absolute difference in clock periods between
two consecutive clock cycles. t JIT(cc) defines the
t
1
cycle-to-cycle jitter.
t ERR(nper)
The cumulative error across n multiple consecu-
tive cycles from t CK(avg).
tERR(nper) =
i+n–1
tCK j – ( n × tCK(avg))
1
j=i
t ERR(nper),act
t ERR(nper),
allowed
The actual cumulative error over n cycles for a
given system.
The specified cumulative error allowance over n
cycles.
t ERR(nper),min
The minimum t ERR(nper).
tERR(nper),min = (1 + 0.68LN(n)) × tJIT(per),min
2
PDF: 09005aef83f3f2eb
2gb_mobile_lpddr2_s4_g69a.pdf – Rev. N 3/12 EN
137
Micron Technology, Inc. reserves the right to change products or specifications without notice.
2010 Micron Technology, Inc. All rights reserved.
